Minimum Order Quantity 25 Piece
Model Number/Name IGHCPL - 24
Type Small Vaccine Carrier, Short Range
Weight Fully Loaded 2.0 Kgs.
External Surface Material HDPE (High Density Polyethylene)
Insulation Material CFC free Polyurethane
External Dimensions 21.5 x 14.5 x 18.5 cms
Vaccine Storage Dimensions 16.8 x 9.5 x 5.3 cms
Brand IGHCPL
Color Blue
Vaccine Storgae Capacity 0.86 Litres
Weight Empty 1.0 Kgs. (With Empty Icepacks)
Internal Lining Material HIPS (High Impact Polystyrene)
Insulation Thickness 20/25mm
Internal dimensions 16.8 x 9.8 x 12 cms
Lid type and Fixings Removable
Specifications :
MODEL IGHCPL -24
TYPE Small Vaccine Carrier, Short Range
WHO PIS Reference Number E-4/89-M
Vaccine Storgae Capacity 0.86 Litres
Weight - fully loaded 2.0 Kgs.
Weight - empty (with empty icepacks 1.0 Kgs.
External Surface Material HDPE (High Density Polyethylene)
Internal Lining Material HIPS (High Impact Polystyrene)
Insulation Material CFC free Polyurethane
Insulation Material CFC free Polyurethane
Insulation Thickness 20/25mm
External Dimensions (L x W x H) 21.5 x 14.5 x 18.5 cms
Internal dimensions (L x W x H) 16.8 x 9.8 x 12 cms
Vaccine Storage Dimensions 16.8 x 9.5 x 5.3 cms
Lid type & Fixings Removable
Number of Ice packs required 2
Number of Ice packs supplied 2
Ice-packs type E5/IP.2
Volume of Icepack 0.40 Litres
PERFORMANCE
Conforming to WHO Specifications E4/VC.0
Cold Life Requirement as per WHO at 43 deg C ± 1 deg C without opening Min. 8 Hours
Actual Cold Life wothout opening 43 deg C ± 1 deg C as Tested by WHO approved Testing Lab, PSB, Singapore 14 Hours 1 minutes
SHIPPING DIMENSIONS
Quantity in each carton (Nos.) 12
Gross Weight (approx.) 16 Kgs.
Size of carton (L x W x H) (approx.) 48 x 46 x 45 cms
Volume of each carton (approx.) 0.10 CBM
No. of Units/20' container 3600
No. of Units/40' container 7584
No. of Units/40' High cube container 8712
Minimum Order Quantity 50 Piece
Brand IGHCPL
Size 0.4 Litres
Material HDPE
MODEL IGHCPL - 4
External Dimension 165 x 96 x 33 mm (Approx.)
Volume of Ice per pack 0.355 Litres
Weight Empty 76 gms
Weight Filled 430 gms
Specifications :
ICEPACKS MODEL IGHCPL -4
Material HDPE (High Density Polyethylene)
WHO PIS Reference Number E-5/25
Size 0.4 Litres
Volume of Ice per pack 0.355 Litres
External dimension (Approx.) 165 x 96 x 33 mm
Weight empty 76 gms
Weight filled 430 gms*
PERFORMANCE
Conforming to WHO/UNICEF Specifications E5 IP.2
SHIPPING DIMENSIONS
Quantity in each carton (Nos.) 230
Gross Weight (approx) 21 Kgs.
Size of carton (LxWxH) (approx.) 85 x 75 x 25 cms
Volume of the carton (approx.) 0.16 CBM
No. of Units/20' container Hinged
No. of Units/20' container 40,020
No. of Units/40' container 81,420
No. of Units/40' High cube container 99,360
