  Plastic Airways

  Brand IGHCPL Material Plastic Usage Hospital Features Disposable
•

  Read more

  Add to Enquiry

  Large Cold Box Long Range

  Minimum Order Quantity 10 Piece Model Number/Name IGHCPL - 316 Type Large Cold Box, Long Range Vaccine Storgae Capacity 22.0 Litres Weight Fully Loaded 49.5 Kgs. Weight Empty 21.9 Kgs. (With Empty Icepacks) External Surface Material LLDPE Internal Lining Material LLDPE Insulation Material CFC free Polyurethane Insulation Thickness 100 mm External Dimensions 77 x 62 x 52 cms Internal Dimensions 52 x 37 x 28 cms Vaccine Storage Dimensions 45 x 30 x 17 cms Lid type and Fixings Hinged Specifications : MODEL IGHCPL -316L TYPE Large Cold Box, Long Range WHO PIS Reference Number E-4/93-M Vaccine Storgae Capacity 22.0 Litres Weight - fully loaded 49.5 Kgs. Weight - empty (with empty icepacks) 21.9 Kgs. External Surface Material LLDPE* Internal Lining Material LLDPE* Insulation Material CFC free Polyurethane Insulation Thickness 100 mm External Dimensions (L x W x H) 77 x 62 x 52 cms Internal dimensions (L x W x H) 52 x 37 x 28 cms Vaccine Storage Dimensions 52 x 37 x 28 cms Lid type & Fixings Hinged Number of Ice packs required 31 Number of Ice packs supplied 31 Ice-packs type E5/IP.1 Volume of Icepack 0.60 Litres Ice-packs type E5/IP.2 Volume of Icepack 0.40 Litres PERFORMANCE Conforming to WHO Specifications E4/CB.4 Cold Life Requirement as per WHO at 43 deg C 1 deg C without opening Min. 48 Hours Actual Cold Life wothout opening 43 deg C 1 deg C as Tested by WHO approved Testing Lab, PSB, Singapore 67 Hours 56 minutes SHIPPING DIMENSIONS Quantity in each carton (Nos.) 1 Gross Weight (approx.) 18 Kgs. Size of carton (L x W x H) (approx.) 66 x 66 x 38 cms Volume of each carton (approx.) 0.18 CBM No. of Units/20' container 140 No. of Units/40' container 300 No. of Units/40' High cube container 415
•

  Read more

  Add to Enquiry

  Vaccine Cold Chain

  Minimum Order Quantity 25 Piece Brand IGHCPL Model Number/Name IGHCPL - 46 Vaccine Storgae Capacity 2.46 Liters Weight - fully loaded 6.36 kg Weight Empty 2.98 kg External Dimensions 27x 27x 32 cm Internal Dimensions 122 x 122 x 19 cm Specifications : MODEL IGHCPL -46 SPECIFICATIONS Results Vaccine storage capacity 2.46 Liters Weightfully loaded 6.36 kg Weight empty 2.98 kg External dimensions 27x 27x 32 cm Internal dimensions 122 x 122 x 19cm PERFORMANCE Cold life witout openings 50 hours 12 minutes at 43 c Warm life 15 hours 57 minutes at 43 c Cool life 9 hours 47 minutes at 43 c Vaccine storage dimensions with frozen icepacks 11.38 x 11.38 x19cm Lid type & fixing Removable External materials High Density polyethylene Internal lining materials High impact polystyrene Insulation materials CFC Free polyurethane Insulation thickness 32/35mm Number of icepacks required 4 Number of ice packs supplied 4 Icepack type required E05/IP.I
•

  Read more

  Add to Enquiry

  Blood Bag Carrier

  Minimum Order Quantity 25 Piece Model Number/Name IGHCPL - 324SS Type Small Cold Box, Short Range Vaccine Storgae Capacity 15.0 Litres Weight Fully Loaded 33.2 Kgs. Weight Empty 14.5 Kgs. (With Empty Icepacks) Material LLDPE Insulation Material CFC free Polyurethane Insulation Thickness 65 mm External Dimensions 65 x 65 x 37 cms Internal Dimensions 48 x 48 x 19 cms Vaccine Storage Dimensions 40 x 40 x 10 cms Lid type and Fixings Hinged Specifications : MODEL IGHCPL -324SS TYPE Small Cold Box,Short Range WHO PIS Reference Number E-4/100-M Vaccine Storgae Capacity 15.0 Litres Weight - fully loaded 33.2 Kgs. Weight - empty (with empty icepacks) 14.5 Kgs. External Surface Material LLDPE* Internal Lining Material LLDPE* Insulation Material CFC free Polyurethane Insulation Thickness 65 mm External Dimensions (L x W x H) 65 x 65 x 37 cms Internal dimensions (L x W x H) 48 x 48 x 19 cms Vaccine Storage Dimensions 40 x 40 x 10 cms Lid type & Fixings Hinged Number of Ice packs required 32 Number of Ice packs supplied 32 Ice-packs type E5/IP.2 Volume of Icepack 0.40 Litres PERFORMANCE Conforming to WHO Specifications E4/CB.4 Cold Life Requirement as per WHO at 43 deg C 1 deg C without opening Min. 48 Hours Actual Cold Life wothout opening 43 deg C 1 deg C as Tested by WHO approved Testing Lab, PSB, Singapore 67 Hours 56 minutes SHIPPING DIMENSIONS Quantity in each carton (Nos.) 1 Gross Weight (approx.) 18 Kgs. Size of carton (L x W x H) (approx.) 66 x 66 x 38 cms Volume of each carton (approx.) 0.18 CBM No. of Units/20' container 140 No. of Units/40' container 300 No. of Units/40' High cube container 415
