Minimum Order Quantity 25 Piece
Model Number/Name IGHCPL - 264SL
Type Small Cold Box,Long Range
Vaccine Storgae Capacity 6.0 Litres
Weight Fully Loaded 26.6 Kgs.
Weight Empty 14.21 Kgs. (With Empty Icepacks)
Material LLDPE
Insulation Material CFC free Polyurethane
Insulation Thickness 100 mm
External Dimensions 63 x 51 x 45 cms
Internal Dimensions 40 x 28 x 20.6 cms
Vaccine Storage Dimensions 33 x 21 x 10 cms
Lid type and Fixings Hinged
Specifications :
MODEL IGHCPL -264SL
TYPE Small Cold Box, Long Range
WHO PIS Reference Number E-4/101-M
Vaccine Storgae Capacity 6.0 Litres
Weight - fully loaded 26.6 Kgs.
Weight - empty (with empty icepacks) 14.21 Kgs.
External Surface Material LLDPE*
Internal Lining Material LLDPE*
Insulation Material CFC free Polyurethane
Insulation Thickness 100 mm
External Dimensions (L x W x H) 63 x 51 x 45 cms
Vaccine Storage Dimensions 40 x 28 x 20.6 cms
Lid type & Fixings Hinged
Number of Ice packs required 26
Number of Ice packs supplied 26
Ice-packs type E5/IP.2
Volume of Icepack 0.40 Litres
PERFORMANCE
Conforming to WHO Specifications E4/CB.1
Cold Life Requirement as per WHO at 43 deg C 1 deg C without opening Min. 90 Hours
Actual Cold Life wothout opening 43 deg C 1 deg C as Tested by WHO approved Testing Lab, PSB, Singapore 134 Hours
Minimum Order Quantity 100 Unit
Model Name/Number IGHCPL -1089
Usage/Application Ambulance
Material Silicon
Modes Of Ventilation CMV(VC)
Patient Age Group Pediatric
